New Surface Install Contactless Time Delay Infrared No Touch Exit Button IR Door Lock Release Switch

New Surface Install Contactless Time Delay Infrared No Touch Exit Button IR Door Lock Release Switch

-4.8 0 Reviews

$103.42

$196.5

Save:47%

Size(inch): Please select an item

one-size

Color: Please select an item

Available: In Stock

Add To Cart Buy Now

Add To Wishlist

Product Description Reviews(0)

Model Number:K3/K4/K404B/K86A/B
Size:see below
Item Type:Exit Button
Origin:Mainland China
Product Name:Infrared Exit Button
Function:Infrared No touch
K3-1 Size:86x55x20mm
K4-1 Size:86x86x20mm
K86A/BSize:86x86x14mm
K404B Size:115x40x14.5mm
Material:ABS Fireproof Plastic
Contact:NO,NC,COM

More Infrared Exit Button, Click follow Picture
K3(Time Delay)
0.3-30 Seconds Time Delay Adjustable
Surface Installation
Material: Plastic
Contact rating: 3A, AC 120V / DC 30V
Input voltage: DC 12V-24V
Output Contact:NO/NC/COM
Working temperature(approx.): 0 to 50 ℃
Response range: Within 10cm
LED indication: Standby: Red LED on, visitors approaching: Green LED on
Size:86x55x20 mm
K4(Time Delay)
0.3-30 Seconds Time Delay Adjustable
Surface Installation
Material: Plastic
Contact rating: 3A, AC 120V / DC 30V
Input voltage: DC 12V-24V
Output Contact:NO/NC/COM
Working temperature(approx.): 0 to 50 ℃
Response range: Within 10cm
LED indication: Standby: Red LED on, visitors approaching: Green LED on
Size:86x86x20 mm
K404B(Time Delay)
0.3-30 seconds time delay adjustable
Surface Installation
Material: Plastic
Contact rating: 3A, AC 120V / DC 30V
Input voltage: DC 12V-24V
Output Contact:NO/NC/COM
Working temperature(approx.): 0 to 50 ℃
Response range: Within 10cm
LED indication: Standby: Red LED on, visitors approaching: Green LED on
Size:115x40x14.5 mm
K86A/K86B(Time Delay)
New Function for 0.3-30 seconds time delay adjustable
Surface Installation
Material: Plastic
Contact rating: 3A, AC 120V / DC 30V
Input voltage: DC 12V-24V
Output Contact:NO/NC/COM
Working temperature(approx.): 0 to 50 ℃
Response range: Within 10cm
LED indication: Standby: Blue LED on, visitors approaching: Green LED on
Size:86x86x14 mm
Diagram
