Screen Size:No Screen
Special Feature:Remote Control
Battery Life:30 Hours & Up
Item Size:73.8(L)*25.9(W)*12.2(H)mm
Out Power:5v
Model Name:JM-VL103D
Voltage:5V
Gps Module:Yes
Origin:Mainland China
GPS type:GPS Tracker
Certification:CE,FCC
With Relay to cut off fuel engine:Yes
Dust & Water Resistance:Yes with IP66
Over-speed alert:Yes
History playback:Yes with 180 days playback
Platorm for EU.Middle East countries:eu.tracksolidpro.com
Web Platform for Asia countries:hk.tracksolidpro.com
Vibration alarm:Yes
Real time position:Yes
Internal 3-axis accelerometer:Yes,Yes
OTA upload software remotely:Yes
Suit for motorcycle and Car:Yes
GSM/GPS antenna:Built-in quad band GSM antenna, GPS ceramic antenna
Standby current:≤5mA
Data storage:32 + 32 Mb
Tracking sensitivity:-165dBm
TTFF (open sky):Avg. hot start ≤1sec
Motorbike GPS tracker:Yes
Updated of VL03:Yes
Motorcycle gps tracker:YES
mini Tracker for scooter:YES
Waterproof gps locator:YES
GPS Tracker for car:YES
Concox GPS tracker:YES
GPS tracker with battery:YES
Cut off fuel remotely:Simple version not support
GPS tracker kind:YES
Mini gps locator:YES
Remote Cut-off (Fuel/Power):YES
Tamper Alert:YES
low battery, speeding, drifting, etc:YES
Positioning accuracy:no more than 2.5m CEP
3.7V industrial-grade Li-Polymer battery:YES
Sensors:Accelerometer
Interface:4 pin (V+, V-, ) ACC, Relay optional
Stop car remotely:YES for updated version
Multi alerts:low battery, speeding, removal, drifting
Wialon platform can be connect:YES
Suit for:Electric Bike, Light Vehicle or Motor
Car gps tracker with relay:Yes optional
gps tracking device:Yes
Vehicle tracker:Yes
GPS tracker with SIM card:Yes
GPS tracking for car:Yes
GPS tracking device:Yes
Wide voltage:9-90V
Driving Behavior Analysis:Yes
GPS Data storage:1000 pieces
Geo-fence alert:Yes with 20 Geo-fence
Suit for scooter:yes
Web Platform for American countries:us.tracksolidpro.com
Warranty:2 years
Moving alarm:Yes
ACC detection:Yes
With RS485 ports:Yes
GPS tracker 4G:Yes
Anti-thieft gps:Yes
Operating temperature:-20℃~+70℃
Position accuracy:no more than 2.5m CEP
Communication system:GSM/LTE
Acquisition sensitivity:-148dBm
Cheap car tracker:Yes
Can cut off fuel:Yes optional
Unique design:Yes
Car GPS locator:Yes
Tracker for motorbike:Yes
gps tracker with SIM:Yes ( only for the areas our SIM card supported)
Free APP:Yes find "TracksolidPro" in app store or google play
E-bike GPS locator:YES
GPS tracker mini:YES
SIM card type:2G, Micro-SIM card
See real time position on Google map:Yes by APP and PC
Can fall back to 2G:YES,Yes
Wateproof tracker:YES IP65 Dust & Water Resistance
Builti in Battery:Yes 270mAh
Positioning system:GPS+BDS+LBS
Frequency:L1
Communication network:GSM/ LTE CAT1
LED indication:GPS (Blue), GSM (Green)
Driving behavior analysis:Harsh turn, harsh acceleration, Harsh braking,
Mini Vehicle GNSS Tracker:YES
Ignition Detection:YES for updated version
Free APP lifetime:YES
Communication protocol:TCP
gps tracker car:YES
2G gps tracker:YES
Concox gps Oiginal:YES
gps location tracker:YES
GPS tracker for motorcycle:YES
LTE Cat 1 Vehicle Tracker:YES
Suit for motorcycle trackin:YES
1). 4G Tracker Work Global
Global use for VL103D GPS tracker for motorcycle 4G car locator, we will send out the correct version E or L to you.
2). Mini size powful function
With RS485 port and battery, driver bahavior monitoring, 9-90V wide volgate 4G gps tracker.
3). Stop Engine Remotely
With relay can stop car remotely by send command Relay,1# or just click the button in TracksolidPRO APP
4). 9-90V Wide Voltage
Suit for all kinds of vehicles tracking, boad, truck, motorbike, car, bus fleet management etc.
4). Slim Design
The smallest size among all Concox and JIMIIOT 4g gps trackers, easy to hide.
5). 270mAH built-in Battery
With built-in battery, can work even power cable was cut and more convinent for testing.
6). Car Battery Protection
No worry about your car or motorbike will drain out the original battery while you open the VL103D battery protection function.
7). Dust & Water Resistance IP66
JIMIMAX VL103D gps tracker suit for SUV, scooter , boat etc help you drive more safety.
8). 4 kinds of Driver behavior monitor
Driving behavior analysis for Harsh acceleration, Harsh braking, Harsh cornering, Collision.
2. Advantages of JIMIOT & Concox JM-VL103D Mini Tracker
1). LTE & GSM Network
Communication via 4G LTE networks with 2G GSM fallback.
2). Configurable Input/Output
Set to alarm button status monitoring by default, also configurable as an extra digital output.
3). Vehicle Battery Protection
Automatically stop drawing power from the car battery when it drops near the threshold.
4). IP66 Dust & Water Resistance
Rugged design ensures continued optimal performance, even in the toughest conditions.
5). RS232 & TTL Interface RS485 interface extends more device usage scenarios.
6). Driving Behavior Analysis (Basic)
Receive alerts when any of 4 kinds of dangerous driving.
3. Packing Details for JIMIMAX VL103D
